Welding surface plates

Welding surface plates

Usage: Welding surface plates are used for the workers to weld something. They are different from the rivet welding surface plates, there is no hole on their surface, flat or T-slots is available. Their advantages are easy to clean, no distortion and good structure stability.

Details

Welding surface plates

Usage: Welding surface plates are used for the workers to weld something. They are different from the rivet Welding surface plates, there is no hole on their surface, flat or T-slots is available. Their advantages are easy to clean, no distortion and good structure stability.

Material: HT200-300
Standard: GB/T22095-2008
Specification: 750x1000-3000x8000mm or customize

specification(Lx W)mm precision grade
0 1 2 3
flatness tolerance (um)
200×200 3.5 7 14 27
300×200 4 8 15 30
300×300 4 8 15 30
300×400 4 8 16 32
400×400 4.5 8.5 17 34
400×500 4.5 9 18 35
400×600 5 10 19 37
500×500 5 10 19 37
500×600 5 10 19 39
500×800 5.5 11 21 43
600×800 5.5 11 22 44
600×900 6 11.5 23 46
1000×750 6 12.5 25 50
1000×1000 7 13.5 27 54
1000×1200 7 14 29 58
1000×1500   16 32 63
1000×2000   18.5 37 74
1500×2000   20 40 80
1500×2500   22.5 45 90
1500×3000   25 50 100
2000×2000   22 44 88
2000×3000   27 53 106
2000×4000   32 64 127
2000×5000   37 75 150
2000×6000   43 86 172
2000×7000   49 97 194
2000×8000   54.5 109 218
2500×3000   28.5 57 114
2500×4000   33 67 133
2500×5000   39 77 154
2500×6000   44 88 176
2500×7000   50 99 198
2500×8000   55 110 221
3000×3000   30.5 61 122
3000×4000   35 70 140
3000×5000   40 80 160
3000×6000   45 90.5 181
3000×7000   51 101 203
3000×8000   56 112.5 225
4000×4000   39 78 156
4000×5000   43 87 174
4000×6000   48 96.5 193
4000×7000   53 107 213.5
4000×8000   59 117 235


Surface: flat or T-slots (any other accessories are available according to your requirement, like V, straight-shaped slots and tapped holes, long holes, grid lines, etc.)
Hardness of the working surface: HB160-240
Surface treatment: hand-scraped or finish-milling
Foundry process: sand casting or centrifugal casting
Molding type: resin sand molding
Painting: primer and face painting
Surface coating: pickling oil and plastic-lined or covered with anticorrosion paint
Precision grade: 2-3
Working temperature: (20±5)°C
Packaging: wooden box
